| Parameter Item | Parameter Value |
|---|---|
| Driving License | A1,A2,B2 |
| Announcement Model | ZZ3317V326GF1 |
| Drive Form | 8X4 |
| Wheelbase | 1950+3225+1350mm |
| Engine | Sinotruk MC11.44-60 |
| Transmission | Sinotruk HW25712XSL |
| Rear Axle Ratio | 5.26 |
| Body Length | 9.58m |
| Body Width | 2.55m |
| Body Height | 3.55m |
| Front Track | 2022/2022mm |
| Rear Track | 1860/1860mm |
| Curb Weight | 15.5 tons |
| Rated Load | 15.37 tons |
| Gross Vehicle Weight (GVW) | 31 tons |
| Tonnage Level | Heavy Truck |
| Approach Angle | 17° |
| Departure Angle | 21° |
| Origin | Jinan, Shandong |
| Segment Market | Urban Construction Muck |
| Energy Type | Diesel |
| License Plate (Yellow/Blue) | Yellow Plate |
| Parameter Item | Parameter Value |
|---|---|
| Engine Model | Sinotruk MC11.44-60 |
| Engine Brand | Sinotruk |
| Number of Cylinders | 6 Cylinders |
| Fuel Type | Diesel |
| Displacement | 10.518L |
| Emission Standard | China VI |
| Maximum Horsepower | 440 HP |
| Maximum Output Power | 327kW |
| Maximum Torque | 2100N·m |
| Maximum Torque Speed | 1000-1400rpm |
| Rated Speed | 1900rpm |
| Engine Form | High Pressure Common Rail + EGR + SCR |
